Overview
- Also available in active version (SCM100ASLT)
- ATC SM75-150 S Soft Dome Mid driver
- Latest 314mm SL Spec Bass driver
- Massive ATC motor assembly
- Wide, even dispersion for pin-point imaging
- 350 watt Class AB tri-amp pack (active version)
- Active filters and overload protection (active version)
- 6 year warranty
- Any veneer to order. Featured veneer: Yew.
Specifications
Drivers: HF 25mm Neodymium, Mid 75mm ATC Soft Dome, LF 314mm SL
Amplitude Linearity (±2dB): 65Hz–17kHz
Frequency Response (±6dB): 32Hz–22kHz
Matched Response: ±0.5dB
Dispersion: ±80° Coherent Horizontal, ±10° Coherent Vertical
Max SPL: 115dB
Crossover Frequencies: 380Hz & 3.5kHz
Connectors: Female XLR
Filters: Active – 4th Order Linkwitz-Riley, Passive – 2nd Order linkwitz-Riley
Amplifier Output: 200w LF, 100w Mid, 50w HF (active version)
Cabinet Dimensions (HxWxD): 1070x397x560mm
Weight: 68kg
